MSA015S Microwave motion sensor
Microwave motion sensor
with Breathing Detection Technology
Microwave motion sensors operate on the principle of "reflection" of microwave radiation. Sensors emit high-frequency electromagnetic waves with a frequency of 5.8 GHz and receive reflected signals from objects.
SPECIFICATION |
|
|
Type: |
Microwave motion sensor with Breathing Detection Technology |
|
Input voltage: |
220-240VAC 50/60Hz |
|
Illumination threshold: |
Daylight threshold: 5 lux / 15 lux / 30 lux / 50 lux / 100 lux / 150 lux / Disable |
|
Maintaining light after leaving the detection area: |
5 S / 30 S / 1 min / 3 min / 20 min / 30 min |
|
High Frequency System: |
5.8 GHz ±75 MHz |
|
Radiation power: |
0.5mW Max |
|
Operating temperature: |
-25℃ … +55℃ |
|
Humidity: |
< 93% RH |
|
Standard: |
CE RoHS |
|
IP rating: |
IP 20 |
|
Action zone: |
150° (wall mounting) |
|
Distance detection: |
100% / 75% / 50% / 25% |
|
Installation height: |
6 m |
|
Nominal load: |
400W (Inductive) 800W (resistive) |
|
Power consumption: |
<0,5W |
|
Warranty: |
5 years |
* The sensor complies with fundamental requirements of applicable EU regulations and product safety legislation and bears the CE symbol.
FEATURES
- High sensitive Breathing Detecting Technology
- Supports high-sensitivity and low-sensitivity modes (for metal ceilings, metal reflector mounting environments)
- Patent Low Impedance Antenna Comply with the latest RED directive Interference-free with flying insects, falling leaves, air vent and wireless signal(Wi, Bluetooth, 4G and 5G)
- Mounting height is up to 6m
APPLICATIONS
- warehouse
- depot
- distribution center
- storehouse
- depository storage
- entrepôt
- stockroom
- granary
